PT-RCQ80

Panasonic OA

Mobile Version | Global Top | 中

1-Chip DLP™ projector

HK$139,000

Brightness : 8,400 lumens (Centre); contrast ratio : 10,000 : 1
Resolution : 4,608,000 pixels / 2715 x 1697 dots
Laser diode light source

Overview

Brightness : 8,400 lumens (Centre); contrast ratio : 10,000 : 1
Resolution : 4,608,000 pixels / 2715 x 1697 dots
Laser diode light source
Separeate LAN/DIGITAL LINK Terminals
Data Cloning Function
Unique Contrast Sync and Shutter Sync Function
Quick Start/Quick off Mode
Multi Monitoring & Control Software and Early Warning Software
Multi-Unit Brightness and Color Control

Specifications


		1-Chip DLP™ projector PT-RCQ80


Projector
General
Panel Type		0.67" 1-Chip DLP™ projector
Lamp		N.A. (Laser diodes light source)
Brightness		8,000 lumens / 8,400 lumens (centre)
Lens		OPTIONAL
Contrast (Full on / Full off)		10,000:1 (Full On/Full Off, Dynamic Contrast Mode: 3)
Resolution (Native / maximum)		4,608,000 pixels / 2715 x 1697 dots (with Smooth Pixel Drive : ON)
Screen Size		1.27–15.24 m (50–600 in), 1.27–5.08 m (50–200 in) with ET-DLE055, 2.54–8.89 m (100–350 in) with ET-DLE035, 2.54–10.16 m (100–400 in) with ET-DLE020, 16:10 aspect ratio
Lens Shift		Vertical +50%, -16% horizontal +30%, -10% (refer to leaflet for different lens )
Keystone Correction Range		Vertical: ±40° (±5° with ET-DLE020, ±16° with ET-DLE060, ±22° with ET-DLE105/ET-DLE085/ET-DLE055, +5° with ET-DLE035), Horizontal: ±15° (±10° with ET-DLE060) (cannot be operated with ET-DLE035/ET-DLE020)
Weight		Approx 24.2 kg (with supplied lens)
Dimensions (W x H x D)		498 x 200 x 581 mm
Power Consumption		880 W
Terminals		SDI In : BNC x 1 : 3G/HD-SDI Inpurt HDMI In : HDMI 19-pin x 1 DVI-D In : DVI-D 24-pin x 1 Multi Projector Sync In : BNC x 1 Multi Projector Sync Out : BNC x 1 Serial In : D-sub 9-pin (female) x 1 Serial Out : D-sub 9-pin (male) x 1 Remote 1 In : M3 x 1 for wired remote control Remote 1 Out : M3 x 1 for link control (for wired remote control) Remote 2 In : D-sub 9-pin (female) x 1 for external control (parallel) LAN : RJ-45 x 1 for network connection, 10Base-T/100Base-TX, compliant with PJLink™ (Class 2), Art-Net Digital Link : RJ-45 x 1 for network, DIGITAL LINK connection (HDBaseT™ compliant), 100Base-TX, compatible with Art-Net, PJLink™ (Class 2), Deep Color, HDCP 2.2, 4K/60p signal input USB : USB Connector (Type A) x 1 for Cloning/Wireless Module (output 5 V/500 mA) Expansion Slot : Open slot for SLOT NX compatible interface board
Replacement Lamp		NA
Optional Accessories		ET-PKD130H 6-axis, High ceiling mount bracket ET-PKD120H High ceiling mount bracket ET-PKD120S Low ceiling mount bracket ET-PKD130B Projector mount bracket ET-MDN12G10 Interface board for 12G-SDI input ET-MDNHM10 Interface board for HDMI® (HDCP 2.2) input ET-MDNDV10 Interface board for DVI input ET-MDNDP10 Interface board for DisplayPort™ AJ-WM50 series Wireless module ET-YFB200G Digital Link Switcher ET-YFB100G Digital Interface Box ET-UK20 Geometry Manager Pro Software Upgrade Kit ET-CUK10/ET-CUK10P Auto Screen Adjustment Uprgrade Kit ET-SWA100 series Early Warning Software ET-NUK10 NFC Upgrade Kit
Optional Lens	Zoom lens	ET-DLE020 (0.280-0.299:1) ET-DLE060 (0.600-0.801:1) ET-DLE085 (0.782-0.977:1) ET-DLE105 (0.978-1.32:1) ET-DLE150 (1.30-1.89:1) ET-DLE170 (1.71-2.41:1) ET-DLE250 (2.27-3.62:1) ET-DLE350 (3.58-5.45:1) ET-DLE450 (5.36-8.58:1)
Optional Lens	Fixed focus lens	ET-DLE035 (0.380:1) ET-DLE055 (0.785:1)
Standard Accessories		Power cord x 1 Wireless remote control unit x 1 Batteries for remote control x 2 Lens Mount Cover x 1
